| Technical Parameter | ||
| Specification | Single Phase In & Out | |
| Rated output capacity | 2000VA/1600W | |
| AC input | Input voltage range | 115-300VAC±5 |
| Input frequency range | (45-55)±0.5Hz | |
| bypass voltage | 80VACx(1±5%)-285VACx(1±5%) | |
| Battery Input | Battery Unit Voltage | 48V |
| Battery installation | Internal | |
| Backup Tim(Half/Full) | Half Load≥10mins; Full Load ≥5 Mins(Standard Type) | |
| Maximum Power Imput Current | <150% of Nominal current | |
| Battery Charge Time | Long Time UPS Depends On The Capacity of External Battery packs | |
| AC output | Output voltage | 220VAC±1%(Inverter output) |
| Output frequency | 50±5HZ(AC Input Normal);50Hz±1%(AC Input Abnormal) | |
| wave form | sine wave THD<3%( linear load) | |
| sine wave THD<8%(Nonlinear load) | ||
| output power factor | 0.8 | |
| Overload ability | 130% Continuous Load: Not Less Than 30S, Recovery Point: 90% Load | |
| Communication and monitoring functions | RS232(Optional 485), Dry Contact, Intelligent Slot(Expandable SNMP, SMS, And Other Monitoring) | |
| Tower | Net.Weight(KG) | 9.8 |
| Unit Dimension(W*H*D)mm | 460*190*330 | |
| Delivery time | standard machine | Quantity > 2 pcs by sea, shipping time: 20 - 35 days; |
| Quantity ≤ 2 pcs by air, shipping time: 5 - 12 days | ||
| long running machine | Quantity > 5 pcs by sea, shipping time: 20 - 35 days; | |
| Quantity ≤ 5 pcs by air, shipping time: 5-12 days. | ||
| Delivery port | SHENZHEN, GUANGZHOU, HONGKONG | |
| Application area | Widely used in financial, telcom, govenment, traffic, manufacture, education etc. | |
| Certification |
ISO9001, ISO14001, CE, ROHS |
|
